Specifications

Engine

• Model: Bobcat 3.4L Diesel
• Gross Power: 74 hp (55.2 kW)
• Fuel Capacity: 44.4 gal (168 L)

Weights

• Operating Weight: 10,127 lbs (4,594 kg)

Performance

• Rated Operating Capacity (35% of Tipping Load): 3,200 lbs (1,451 kg)
• Tipping Load: 9,143 lbs (4,147 kg)
• Travel Speed: 6.0 mph (9.7 km/h)
• Travel Speed (2-speed option): 8.3 mph (13.4 km/h)
• Ground Pressure: 4.2 psi (28.96 kPa)

Hydraulics

• Standard Flow: 23.0 gal/min (87.1 L/min)
• System Relief Pressure: 3,550 psi (24.5 MPa)

Dimensions

• Height: 81.3 in (206.5 cm)
• Width (with bucket): 80 in (203.2 cm)
• Length (with bucket): 141.6 in (359.7 cm)
• Length (without attachment): 114.3 in (290.3 cm)
• Dump Height: 104.3 in (264.9 cm)
• Dump Reach: 35.2 in (89.4 cm)
• Ground Clearance: 7.8 in (19.8 cm)

Undercarriage

• Track Width: 17.7 in (45 cm)
• Track Length on Ground: 63.7 in (161.8 cm)
