Specifications

Engine

• Model: JCB EcoMAX T4F
• Type: 4-stroke, direct injection, turbocharged
• Number of Cylinders: 4
• Displacement: 268.6 in³ (4.4 L)
• Gross Power: 125 hp (93 kW) @ 2,200 rpm
• Max Torque: 406 lbf·ft (550 Nm) @ 1,500 rpm

Dimensions

• Length with Bucket on Ground: 20 ft 8 in (6.29 m)
• Width over Tires: 7 ft 8 in (2.33 m)
• Height to Top of Cab: 10 ft 1 in (3.08 m)
• Wheelbase: 9 ft 2 in (2.8 m)
• Ground Clearance: 1 ft 3 in (0.38 m)
• Bucket Width: 7 ft 10 in (2.4 m)
• Bucket Capacity (Heaped): 2.0 yd³ (1.6 m³)
• Dump Clearance at Max Raise: 8 ft 11 in (2.67 m)
• Hinge Pin Max Height: 11 ft 8 in (3.56 m)
• Reach at Max Lift and Dump: 3 ft 1 in (0.94 m)

Performance

• Operating Weight: 21,422 lbs (9,717 kg)
• Breakout Force: 15,737 lbf (7,138 kgf)
• Turning Radius (over Tires): 18 ft 2 in (5.54 m)
• Articulation Angle: 40°
• Rear Axle Oscillation: 11°

Transmission

• Type: Smooth shift Powershift ZF 4WG115
• Number of Forward Gears: 4
• Number of Reverse Gears: 3
• Max Speed - Forward: 31.1 mph (50 km/h)
• Max Speed - Reverse: 23.7 mph (38 km/h)

Hydraulic System

• Max Operating Pressure: 3,480 psi (240 bar)
• Relief Valve Setting: 3,190 psi (220 bar)
• Pump Flow Capacity: 41.3 gal/min (156 L/min)
• Raise Time: 4.9 seconds
• Dump Time: 2.1 seconds
• Lower Time: 3.3 seconds
• Total Cycle Time: 10.3 seconds
• Pump Type: Variable displacement piston pump

Capacities

• Fuel Tank: 30.7 gal (116 L)
• DEF Tank: 5.3 gal (20 L)
• Hydraulic System Fluid: 41 gal (155 L)

Electrical System

• Operating Voltage: 24 V
• Alternator Supplied Amperage: 100 A
