2019 CAT 242D Skid Steer Loader Reverse Camera CAB/HEAT/AC!! Two(2) Speed!! Pilot Controls!! Hydraulic Bucket Coupler!! ONLY 330 HOURS!!! LIKE BRAND NEW!!
Specifications
Engine
- Model: Cat C3.3B DIT (turbo)
- Gross Power: 74.3 hp (55.4 kW)
- Net Power: 73.2 hp (54.6 kW)
- Displacement: 203 in³ (3.3 L)
- Fuel Capacity: 27.7 gal (105 L)
Weights
- Operating Weight: 6,980 lbs (3,167 kg)
Performance
- Rated Operating Capacity: 2,150 lbs (975 kg)
- Tipping Load: 4,300 lbs (1,950 kg)
- Breakout Force - Tilt Cylinder: 5,034 lbs (2,284 kg)
- Travel Speed (1-speed): 7.5 mph (12.1 km/h)
- Travel Speed (2-speed option): 11.5 mph (18.5 km/h)
Hydraulics
- Standard Flow: 20 gal/min (76 L/min)
- High Flow (optional): 30 gal/min (113.6 L/min)
- System Relief Pressure: 3,335 psi (23,000 kPa)
Dimensions
- Length with Bucket on Ground: 137.3 in (3,487 mm)
- Length without Bucket: 108.9 in (2,767 mm)
- Width over Tires: 66 in (1,676 mm)
- Height to Top of Cab: 82 in (2,082 mm)
- Wheelbase: 43.5 in (1,105 mm)
- Ground Clearance: 8.7 in (222 mm)
- Departure Angle: 27°
- Maximum Overall Height: 154.2 in (3,917 mm)
- Bucket Pin Height at Maximum Lift: 121.1 in (3,076 mm)
- Reach at Maximum Lift and Dump: 21.7 in (552 mm)
- Clearance at Maximum Lift and Dump: 90 in (2,285 mm)
Features
- Vertical Lift Design: Provides extended reach and lift height for quick and easy truck loading.
- Sealed and Pressurized Cab Option: Offers a cleaner and quieter operating environment with excellent work tool visibility.
- Advanced Display (optional): Provides on-screen adjustments for implement response, hystat response, and creep control.
- Standard Two-Speed Travel: Enhances performance and production capability.
- Cat "Intelligent Leveling" System: Offers features such as dual-direction self-level, work tool return to dig, and work tool positioner.
