PRICE FIRM NO TAX OR FEES

6MONTH/500HR FULL WARRANTY!

Machine was just fully cleaned, greased, serviced and looked over! Photos just taken! Financing & Delivery Available!
- ONLY WELL KEPT 725 Hrs
- 1 OWNER!
- All Original Yellow paint!
- Enclosed HEAT/AC/RADIO
- Hydraulic Thumb
- Long Stick
- 2 speed
- 12", 24” & 36″ tooth buckets
- 42 Hp
- 11,500 Lbs
Machine is READY TO WORK

Key Specifications:

• Operating Weight: 11,443 lbs (Cab, Long Stick)
• Maximum Dig Depth: 144 in
• Maximum Reach: 235 in
• Maximum Dump Clearance: 154 in
• O/A Shipping Dimensions:
  • Height: 100 in
  • Length: 208 in
  • Track Width: 78 in

Performance & Hydraulics:

• Hydraulic System Type: Load Sensing Hydraulics with Variable Displacement Piston Pump
• Pump Flow: 39.6 GPM @ 2,400 RPM
• Operating Pressures:
  • Swing: 3,132 PSI
  • Equipment & Travel: 3,553 PSI
• Digging Forces:
  • Bucket: 10,050 lbs
  • Stick (Standard): 5,550 lbs
  • Stick (Long): 4,788 lbs

Engine & Powertrain:

• Engine Model: CAT C2.4
• Net Power: 40.2 HP @ 2,200 RPM
• Displacement: 146 cu in
• Fuel Tank Capacity: 16.6 gal
• Travel Speed:
  • High: 2.7 mph
  • Low: 1.7 mph

Undercarriage & Track System:

• Track Type: Center Flange
• Track Shoe Width: 16 in
• Carrier Rollers: 1
• Track Rollers: 4

Operator & Safety Features:

• ROPS Certified (ISO 12117-2)
• TOPS Certified (ISO 12117)
• Cab with Air Conditioning
• Automatic Swing Brake
• Hydraulic Release System

Blade Dimensions & Capabilities:

• Blade Width: 6.5 ft
• Blade Height: 14.8 in
• Maximum Blade Lift Height: 15.9 in
• Maximum Blade Dig Depth: 21.9 in

Lift Capacities (At Ground Level)

Lift Point Radius: 9'8” (3000 mm)

• Blade Down - Front: 5,159 lbs
• Blade Up - Front: 3,197 lbs
• Blade Down - Side: 2,646 lbs
• Blade Up - Side: 2,359 lbs

Lift Point Radius: 13'1” (4000 mm)

• Blade Down - Front: 2,778 lbs
• Blade Up - Front: 1,676 lbs
• Blade Down - Side: 1,411 lbs
• Blade Up - Side: 1,257 lbs
