Specifications

Engine

• Model: Kubota D1703M-DI-E4
• Type: Diesel, water-cooled, 3-cylinder
• Displacement: 100.5 cu in (1,647 cc)
• Gross Power: 24.8 HP (18.5 kW)
• Net Power: 23.9 HP (17.8 kW)
• Rated RPM: 2,200

Dimensions

• Overall Length: 15 ft 7 in (4,750 mm)
• Overall Width: 5 ft 7 in (1,700 mm)
• Overall Height: 8 ft 1 in (2,470 mm)
• Ground Clearance: 11.3 in (288 mm)
• Tail Swing Radius: 3 ft 1 in (950 mm)

Operating Weight

• With Canopy: 8,129 lbs (3,687 kg)
• With Cab: 8,499 lbs (3,856 kg)

Performance

• Max Digging Depth: 9 ft 8.9 in (2,970 mm)
• Max Dumping Height: 11 ft 1.3 in (3,385 mm)
• Max Digging Radius at Ground: 16 ft 11.2 in (5,160 mm)
• Boom Swing Angle (Left/Right): 75° / 55°
• Travel Speed (Low/High): 1.9 mph (3.0 km/h) / 2.9 mph (4.6 km/h)
• Arm Breakout Force: 4,451 lbs (2,019 kg)
• Bucket Breakout Force: 7,924 lbs (3,594 kg)

Hydraulic System

• Pump Capacity: 20.6 GPM (78.0 L/min)
• Auxiliary Hydraulic Flow: 15.8 GPM (60.0 L/min)
• System Pressure: 3,134 psi (21.6 MPa)

Fuel and Fluid Capacities

• Fuel Tank: 12.4 gal (47.0 L)
• Hydraulic Reservoir: 11.8 gal (44.6 L)
• Hydraulic System: 16.1 gal (61.0 L)
• Engine Oil: 1.4 gal (5.3 L)
• Cooling System: 1.5 gal (5.7 L)

Features

• Zero Tail Swing: Yes
• Auto Idle: Standard
• Adjustable Auxiliary Flow: Standard
• Angle Blade Option: Available
• Cab with HVAC: Available
