This 2023 Caterpillar 816 is a high-performance, used machine with only 25 hours of operation, offering like-new capabilities at a competitive price. Powered by the reliable Cat C7.1 engine, it meets U.S. EPA Tier 4 Final emissions standards, ensuring compliance with stringent environmental regulations.
Whether you’re looking to enhance your fleet or tackle tough projects, this 2023 Caterpillar 816 is a perfect choice. Contact us today for more details or to arrange a viewing!

Engine Overview:

• Engine Model: Cat C7.1
• Gross Power (SAE J1995:2014): 284 hp
• Net Power (SAE J1349:2011): 249 hp
• Net Power (ISO 9249:2007): 249 hp
• Engine Power (ISO 14396:2002): 275 hp
• Rated Speed: 2200 rpm
• Peak Torque (1,400 rpm): 902 ft-lb
• Torque Rise: 52%
• Bore: 4.1 in (104 mm)
• Stroke: 5.3 in (135 mm)
• Displacement: 427.8 in³ (7.0 L)
• High Idle Speed: 2270 rpm
• Low Idle Speed: 800 rpm
• Maximum Altitude without Derating: 9,842.5 ft (3,000 m)

Emissions Compliance:

• Meets U.S. EPA Tier 4 Final / EU Stage V / Japan 2014 / Korea Tier 4 Final
  Compliant with U.S. EPA Tier 4 Final emissions standards.

Operating Specifications:

• Operating Weight: 57,345 lb

Transmission:

• Transmission Type: Cat Planetary Power Shift
• Travel Speeds (Forward):
  • First: 4.1 mile/h
  • Second: 7.5 mile/h
• Travel Speeds (Reverse):
  • First: 4.8 mile/h
  • Second: 8.5 mile/h

Hydraulic System – Lift/Tilt:

• Lift/Tilt System – Circuit: Pilot-operated LS valve with EH
• Lift/Tilt System: Variable displacement piston
• Maximum Flow at 2,200 rpm: 23.5 gal/min
• Relief Valve Setting – Lift/Tilt: 3,190 psi
• Pilot System: Open center, fixed displacement gear
• Pilot Relief Valve Setting: 3,046 psi

Hydraulic System – Steering:

• Steering System – Circuit: Pilot, Load Sensing
• Steering System – Pump: Piston – Variable Displacement
